Lathes

Daewoo Puma 240L

Our Daewoo Puma 240L is self-running with a bar feed and parts catcher, allowing for faster and more efficient production. With this machine we can hold tolerances to +-.0001" at a high rate of repetition.

• Bar feed capability
• Parts catcher
• Through hole spindle: 2.5"
• Swing over bed: 22.4"
• Swing over saddle: 15.7"
• Max turning diameter: 16.6"
• Max turning length: 25.5"
• Bar working diameter: 3.0"
• Spindle speed: 4,000 RPM
• 12 Tool Stations
• Tail stock
• Main spindle motor: 25 HP
• Bar feed
• Rigid tapping

Hitachi-Seiki 5NE-1100

Lathe for oversize parts and heavy cutting

• Chuck Size: 15 "
• Bar Capacity: 4 "
• Turning Dia: 17.71 "
• Swing: 27.5 "
• Power: 30 HP
• Max RPM: 1800 RPM
• Tailstock

Haas SL-20 CNC lathe

• Max bar capacity: 2"
• Max cutting diameter: 10.3"
• Max swing over front apron: 23"
• Cutting length Z-Axis: 20"
• Spindle Motor: 20 HP
• Spindle Speed: 4,000 RPM
• Turret positions: 10
• 8" Chuck
• Programmable tail stock
• Parts catcher
• Rigid tapping

HAAS MINI LATHE GANG STYLE

• Max swing over front apron: 10.5"
• Max turning diameter: 5.8"
• Max machining length: 7.99"
• Max spindle speed: 6,000 RPM
• Bar capacity: 1.06"
• Chuck size: 5C Collet
• Main motor: 7.5 HP
• Parts catcher
• Rigid tapping
• Bar feed
